Product Overview

The Siemens SQM33 series burner servomotors are high-precision actuators designed to control and position air dampers, gas valves, and oil control valves in oil and gas burner systems. These actuators regulate combustion components according to the burner load to maintain stable and efficient burner operation.

The SQM33 series is commonly used with Siemens electronic fuel-air ratio control systems and burner management systems such as LMV2 and LMV3, allowing advanced modulation and accurate control of combustion processes.

Unlike traditional actuators with mechanical cams, the SQM33 series is typically electronically controlled through the burner management system, which manages actuator positioning with high precision.

These actuators are compact, high-speed units designed for industrial burners, boilers, furnaces, and process heating systems, where precise positioning and reliable performance are required.

Key Features

Compact actuator for air dampers and fuel control valves

Designed for oil and gas industrial burners

Compatible with Siemens LMV2 and LMV3 combustion management systems

High-precision electronic positioning control

Stepper motor technology for accurate modulation

Reliable operation in industrial environments

Durable construction with IP54 protection

Suitable for modulating burner systems

Applications

• Industrial gas burners

• Industrial oil burners

• Dual-fuel burner systems

• Steam boiler burners

• Industrial furnaces

• Process heating plants

• Thermal oil heaters

Why Choose Siemens SQM33 burner servomotor?

Trusted Siemens combustion control technology

Precise air-fuel ratio regulation

Seamless integration with Siemens burner management systems

Compact design for easy installation

Reliable performance for continuous industrial operation

High accuracy for modulating burners

Technical Description

The Siemens SQM33 burner servomotor is an electronic actuator used to drive and position air dampers and fuel control valves in industrial combustion systems. The actuator operates according to signals from the burner management system, allowing precise control of combustion parameters.

The SQM33 uses high-precision electronic control and stepper motor technology, enabling accurate positioning without mechanical cam adjustments.

The actuator can deliver rated torque between approximately 1.2 Nm and 3 Nm, depending on the model, making it suitable for compact industrial burner systems.

It typically operates with 24 V control voltage and supports integration with Siemens combustion management systems for fully automated burner operation.
